Surface Mounted Automatic Vehicle Restraint Systems
The Karen SMVR-800 Surface mounted automatic vehicle restraint allows the operator to block the vehicle at dock before the transhipment begins and to release the vehicle once the transshipment is complete by simply pressing push buttons on the control cabinet. A signalization system by two-tone lights (for the driver) and by LED lights (for the operator) enables a simplified use for each participant.
Karen SMVR-800 is an surface mounted automatic locking system of the truck. It was designed to enhance security of operators limiting the risks of accidents that occur generally during transhipment operations. The Karen’s SMVR-800 allows the operator to lock the vehicle in loading dock before the start of loading operations / unloading and to release the vehicle once the transhipment is complete by simply pressing the buttons on the control panel. A two-tone signaling system (for the driver) and LED lights (for the internal operator) allows use simplified for each participant.
Karen SMVR-800 system is a surface mounted automatic (truck, lorry, trailer) wheel locking system. It is designed to prevent the truck from sliding forward during loading and to increase loading safety. Factories and Logistics tops now prefer the Karen SMVR-800 system, which limits the risks of accidents at loading sites. Our products, which operators use quickly and safely, are user-friendly. Typically during transfer-loading operations, Karen’ SMVR-800 allows the operator to lock the vehicle to the loading dock 100% securely. Before the loading process starts, after the vehicle is locked to the loading dock, PLC automation system and software and all equipment communicate with each other. The vehicle locked information is transmitted to the automatic dock leveler, the motorized industrial garage door, and the dock shelter. All this dry contact information is processed. All systems work in partnership with PLC based software management system .
Working logic ;
1. Vehicle tire wheel is locked.
2. The loading bellows received the information and went to the forward closing position and the indoor-outdoor air circulation was interrupted.
3. The loading ramp has been activated.
4. Factory industrial panel loading door door opened.
Karen SMVR-800 system is a surface mounted automatic vehicle tire locking system. It does not require digging in the factory site. It is assembled and put into use very quickly in your field. It is guaranteed for 2 years. There is a guarantee of 10 years of spare parts availability.
For security even under the most extreme weather conditions the Karen SMVR-800 Series surface-mounted restraint is the most rugged wheel restraint solution. Its above-ground mount means operations won’t halt no matter what Mother Nature brings while a hydraulic-operated wheel chocking system allows for simple push-button control that doesn’t impede lift gate operation or interfere with landing gear. And with self-lubricated guide bearings and no mechanical drive components to wear out, maintenance has never been simpler.
PARTS
- Capable of securing virtually any truck or vehicle configuration
- Available in both manually operated and hydraulically operated models
- Heavy-duty steel construction ensures long structural life
- LED interior/exterior lights for superior communication
- Power led green-red lights
- Sounder Signal
- Remote control buttons
- Loop dedectors
- Human safety photocell sensors
- Choose from above-ground and in-ground mounting to fit your loading dock needs and conditions
