Karen system Horizontal high speed door , Opening time is twice as fast due to the lateral opening of this door and unlike vertically opening doors, the complete opening height is immediately accessible for the user. With an opening speed of up to 5 m/s and its closing speed of up to 2.5 m/s the Karen Horizontal high speed rool-up door represents the reliable solution for a fast and safe passage traffic.
Karen Horizontal Roll-Up High Speed Door Specification
Lateral opening of both door leaves simultaneously, thus half the opening time.
Opening Speeds of up to 5 m/s (with option sprint) for fast, safe traffic flow.
For widths up to 4.5 m and heights up to 4.5 m.
Entire passage height immediately available.
Tear-resistant polyester door leaves with PVC coating.
Transparent vision strip for continuous inter-visibility.
No contact of door leaves to personnel or goods.
Short opening and closing cycles reduce draught and heat loss.
Closing edge safety devices and photocells for additional safety.
Comprehensive selection of sensors, activators, detectors.
vertical guides with seals to prevent draughts and the ingress of dust, insects and vermin.
Single or double-skinned application, depending on the need for protection against noise, cold or wind.
They are available not only in a wide variety of sizes and uses, but as well in different options ensuring a greater efficiency in each case.
Achieve maximum environmental control and separation at the door opening with Karen Horizontal High Speed Doors. The main function of a high speed door is to act as a barrier. High speed doors protect us from harm, save energy and help us to separate processes for optimal productivity. A Roll-up high speed door’s most important job is to simply open and close quickly and safely every time you need it.
Karen’s revolutionary line of Horizontal Roll-up high speed doors is designed with these efficiencies in mind to bring your workflow to its high potential. Known for high speed, low maintenance, and maximum uptime, Karen doors offer the industry’s widest range of solutions to fit your every need.
Karen has a large collection of high performance, high speed door solutions in roll-up and bi-parting designs, available in versatile track configurations. Capable of moving at 100 inches per second (2.5 m/sec), the cycle times of Karen doors maximize energy savings by minimizing the amount of air that can escape each time the doors open and close. Unlike traditional hard bi-parting doors, flexible Karen Series doors have the ability to withstand forklift impact and snap right back into their tracks. This is a huge benefit in a warehouse space, where damaged doors can mean significant expenses in terms of downtime and service calls, as well as energy loss.
